Norman 40 | № 424
Measurements+-
Length over all 12.00 m
Length waterline 9.50 m
Beam 3.90 m
Draft 2.00 m
Draft 1.50 m
Draft keel/centreboard 1.10 / 2.00 m
Displacement (steel) 9.30 t
Displacement (aluminium) 7.70 t
Ballast (steel) 2.80 t
Ballast (aluminium) 3.40 t
Sail area fractional rig 98.40 m²
The NORMAN is the answer to the demand for a comfortable sea-going sailing yacht. The most modern constructions and design vision is embodied in this yacht. It results in strong, robust and fast ship. The construction conforms to Lloyd's Register standards. One or two couples can live aboard for years and see the world.
Particularly if you want to make long crossings, a fast sailer is ideal. Because lengthy crossings don't need to be endlessly long and eventually give rise to tiredness and irritation. Finally, there is less need to revert to the engine.
The interior comprises two or three spacious cabins and a saloon of 3.50 x 3.50 metres. It goes without saying that toilet area with shower, galley and chart table are also largely dimensioned.
The superstructure enables plenty of light to enter the saloon. How do you make a motor-sailer that doesn't look like one and behaves like a real sailing ship? The answer is the NORMAN.
The deck saloon is graceful and completely in harmony with the lines of a sailing ship. The spacious saloon provides good vision and has a comfortable round seat. By the application of modern materials it is possible, without heavy constructions, to create large windows capable of withstanding heavy seas. Here also layout variations with two or three comfortable cabins are projected. The special shower unit saves much space.
Those wishing to sail for the rest of this century with a modern, comfortable deck saloon yacht, will choose the NORMAN
|
DIGITAL BOAT PLANS
|
Click on prices to order
|
STUDY PLANS
|
EUR 15
|
BUILDING PLANS: Multi-chine Steel & Aluminium - Quick Assembly
|
EUR 1800
|
BUILDING PLANS: Round-bilge Steel & Aluminium
|
EUR 2050
|
|
